The Allen-Bradley 1764-24BWA is a base unit for the MicroLogix 1500 PLC family, featuring 12 discrete inputs and 12 relay outputs with a wide AC line power supply. Designed to house a compatible processor, it provides integrated I/O, high-speed inputs, and a built-in communication port for flexible control applications in industrial automation.
Technical details
| Specification | Details |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Line | MicroLogix 1500 |
| Model / Part No. | 1764-24BWA |
| Type | PLC Base Unit |
| Embedded Inputs | 8 standard 24 V DC discrete inputs + 4 high-speed 24 V DC inputs |
| Embedded Outputs | 12 relay outputs |
| I/O Voltage | Inputs: 24 V DC sink/source; Outputs: relay contacts supporting up to 24-125 V DC / 120-240 VAC (depends on load) |
| High-Speed I/O | 4 high-speed inputs (20 kHz) |
| Line Power Supply | 85–265 VAC, 47–63 Hz |
| Power Consumption | ~88 VA |
| User Power Output | 24 V DC @ 400 mA (max, with capacitance rating) |
| Communication Port | RS-232 (Channel 0) for programming/communications |
| Compatible Processors | Works with MicroLogix processors such as 1764-LSP/1764-LRP |
| Max Expansion I/O | Supports up to 512 total I/O points (with expansion) |
| Operating Temp. Range | 0 °C – 55 °C (32 °F – 131 °F) |
| Storage Temp. Range | -40 °C – 85 °C |
| Mounting | DIN-rail or panel mount |
| Typical Application | Small to mid-range machine and process control |
